Tektronix 475A +options 4, 07,78 +DM44 service manuals


Tektronix 475A Service Manual INCLUDING OPTIONS (070-2162-00), plus DM-44 Service Manual (070-2036-01) in PDF on CD
(No need to "email for samples," so no need to worry about getting sold to a SPAM list!)
(Please read FAQ or "About Me" Page)
This manual covers maintenance (including calibration), servicing and also has a section on operation of the Tektronix 475A Oscilloscope, including Options 4, 7, and 78, plus the DM44 DVM option. They are both scanned from the original manufacturer's manuals. The scans came out well, and all information available in the original manuals is available here.
Text with photos: 600dpi grayscale (contrast adjusted)
Text with Drawings: 600dpi black and white
Schematics: 600dpi black and white
Schematics and board overlays with color notes: 600dpi 256 colors
Scan parameters of the standard res PDF: The standard res PDFs are done in resolutions that vary depending on individual page content, but are never higher than needed to produce a useable quality, quickly navigable file that will do the job without consuming more time and resources than are needed. They are also text-searchable! All original manual pages are supplied, with no pages added or subtracted (NO shareware begging pages! NO extraneous company logos on every page! NO fake copyrights on schematics!)
Along with the 475A Service Manual is the full service manual for the DM44 multimeter accessory, also provided in our fast, text-searchable standard resolution as well as the 300/600 dpi very high resolution.
"AND IF THAT'S NOT ENOUGH FOR YOU":
As "bonus" material, includes the Tektronix Semiconductor Parts Catalog, plus an interesting and informative Articles PDF as well as a useful text-searchable scan of the 1990 Tektronix Catalog, featuring almost 3,000 Tektronix Products, all at no additional charge!
