LAMBDA 0-120/240V DUAL OUTPUT VARIABLE DC POWER SUPPLY
PLEASE CLICK TWICE ON THE SCREEN BELOW TO VIEW THE DAVID RIDDLE COMPANY INFORMATIONAL VIDEO
IMPORTANT INFORMATION: WE OPERATE A PROFESSIONAL FACILITY THAT EXPERTLY REBUILDS THESE DC LABORATORY POWER SUPPLIES TO MEET ORIGINAL FACTORY SPECIFICATIONS.
EACH POWER SUPPLY IS DISASSEMBLED, INSPECTED, TESTED, AND ANY REQUIRED ELECTRICAL OR MECHANICAL PARTS ARE REPAIRED OR REPLACED, THE ENTIRE UNIT IS CLEANED, AND IF NEEDED, PROFESSIONALLY RE-PAINTED!
AFTER CAREFUL RE-ASSEMBLY, EVERY POWER SUPPLY IS FULLY TESTED FOR ALL FUNCTIONS AT THE MAXIMUM RATED LOAD IN OUR FULLY EQUIPPED TEST LAB!
THE LAMBDA LPD-424A-FM, IS A DUAL OUTPUT, VARIABLE, PRECISION REGULATED DC LAB POWER SUPPLY THAT CAN BE UTILIZED FOR ANY APPLICATION IN ELECTRONIC CIRCUIT DESIGN OR REPAIR AND COMPONENT TESTING IN TUBE AND SOLID STATE CIRCUITS.
THIS POWER SUPPLY IS THE PERFECT PIECE OF PROFESSIONAL GEAR FOR USE IN DESIGNING AND REPAIRING TUBE AUDIO AND OTHER ELECTRONIC EQUIPMENT.
THIS UNIT CAN ALSO FUNCTION AS THE ULTIMATE CAPACITOR "CHARGER / RE-FORMER" PROVIDING COMPLETE CONTROL OF CHARGING / RE-FORMING CURRENT AND END OF "FORMING" VOLTAGE! (IMPORTANT NOTE: A PROPERLY RATED "BLOCKING" DIODE MUST BE INSERTED IN SERIES WITH THE CAPACITOR BEING FORMED TO PREVENT CATASTROPHIC DAMAGE TO THE POWER SUPPLY!)
THIS POWER SUPPLY PROVIDES DUAL OUTPUTS OF 0-120 VOLTS @ 0-0.38 AMPS OUTPUT, EACH WITH VARIABLE FINE AND COARSE CONTROL KNOBS FOR VOLTAGE AND CURRENT ADJUSTMENTS. THE DUAL OUTPUTS EACH PROVIDE, 0-120 VOLTS @ 0-0.38 AMPS, CONSTANT VOLTAGE AND/OR CONSTANT CURRENT (C/V, C/C).
THESE TWO SUPPLY OUTPUTS CAN PROVIDE +/- SUPPLY RAILS OR CAN BE USED INDEPENDENTLY AND IN SERIES FOR GREATER VOLTAGE ( 0 - 250 VOLTS @ 0 - 0.38 AMPS ) OR IN PARALLEL FOR GREATER CURRENT OUTPUT ( 0 - 120 VOLTS @ 0 - 0.76 AMPS ).
THE ANALOG METERS PROVIDE PRECISION READINGS OF BOTH VOLTAGE AND CURRENT. THE OUTPUT CONNECTIONS ARE STANDARD "BANANA" TYPE 5 WAY BINDING POSTS. ALSO, REAR PANEL CONNECTIONS PROVIDE REMOTE SENSE AND VOLTAGE PROGRAMING/TRACKING CAPABILITIES.
THIS IS TRULY A LABORATORY GRADE POWER SUPPLY WITH HUM AND NOISE SPECIFICATIONS MEASURED IN MICRO VOLTS AND SUPPLY REGULATION ACCURATE TO +/- .01%.
THE PHYSICAL MEASUREMENTS OF THIS UNIT ARE 8" x 10" x 4.5".
LAMBDA MAKES THE FINEST LABORATORY DC POWER SUPPLIES IN THE WORLD AND THIS POWER SUPPLY PROVES IT!
TO VIEW THE POWER SUPPLY HANDBOOK PLEASE CLICK ON THE FOLLOWING HYPERLINK:
THIS UNIT HAS BEEN COMPLETELY TESTED IN OUR FULLY EQUIPPED LAB AND IS GUARANTEED TO BE WORKING AND MEETING ORIGINAL FACTORY SPECIFICATIONS.
LAMBDA LPD-424A-FM DUAL OUTPUT DC POWER SUPPLY B24-0835-40-W
