Oz~atlas/craftsman 6" lathe no. 618 manual, parts lists
"6" Lathe NO. 618 Instructions and Parts"
This is a reproduction, not a photocopy, of an Atlas 6" Lathe NO. 618 Instructions and Parts. This lathe was also sold under the Craftsman brand name. This manual contains information on setup, lubrication, maintenance, and controls as well as a complete parts list and exploded views and adjustments. This manual has great information and description of setting up the lathe to a bench. This manual will help you with setting up and running an Atlas Lathe.
Identification and Safety.............................................................................................1,2
Leveling and Mounting...............................................................................................3,4
Gear Clearance............................................................................................................5
Wiring Instructions........................................................................................................6
Lubrication Chart..........................................................................................................7
Unit Assemblies............................................................................................................8
Carriage and Compound Parts Diagrams..................................................................9,10
Headstock Parts Diagram............................................................................................11
Lead Screw, Change Gears, Gear Guard and Lathe Bed Parts Diagram.......................12
Countershaft and Tailstock Parts Diagram....................................................................13
Threading Chart..........................................................................................................14
I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear; they are then comb bound with heavy cover pages so they lie flat on the workbench.
Be sure to add my store to your favorites list!
I am adding new manuals all the time.
PLEASE READ the return policy and COMPLETE description of the manual.
Because of the nature of this product, I do not accept any returns or exchanges
under any circumstances. If you have any questions, email me or send me a picture first. I
