Tektronix TM503/TR503 100KHZ-1.8GHZ tracking generator
Item Description And Condition:
The TM503/TR503 powers up and works flawlessly. One picture shows its output connected directly to the spectrum analyzer input displaying a -10 dBm signal over its operating frequency range of 100 kHz to 1.8 GHz. Another picture shows its output connected to the spectrum analyzer through a 420 MHz low-pass filter. Both pictures reflect the correct response for their configuration. I have used this TM503/TR503 in various measurement configurations over the last four years and it has always worked well for me. Thanks for looking.
From The Tektronix TM503 And TR503 Instruction Manuals....
Frequency range: 100 kHz to 1.8 Ghz
Maximum output level: 0 dBm +/- 0.5 dB
Output level range: 0 dBm to -59 dBm
Output level adjustment steps: 0 to 9 dB in 1 dB steps; 0 to 50 dB in 10 dB steps
Flatness: +/- 2.25 dB over its operating frequency range
Residual FM (peak-to-peak): <10 Hz
TM503 Physical Dimensions (front lift retracted):
Weight: 18.0 lb (TM503 and TR503)
