P.h. group 4C100T hydraulic four-post press
P.H. GROUP MODEL 4C100T HYDRAULIC, DOWN-ACTING, FOUR-POST PRESS*
Capacity: 100 Ton
Stroke: 39" (Maximum)
Daylight: 48"
Closed Height: 9"
Distance Bed to Floor: 30" (w/8" Raisers)
Platen Size: 104" L-R x 54" F-B
Distance Between Posts: 98-1/2" L-R x 38-1/2" F-B"
Main Hydraulic Cylinder Bore: 8"
Maximum PSI: 2,500
EQUIPPED WITH:
Allen-Bradley SLC-5/04 PLC
PanelView 550 Programmer
Pneumatic Safety Locks
Top Mounted Hydraulic Power Unit
Vickers Pump & Valving
50 HP AC Main Drive (Pump) Motor 230/460/3/60
Electrical Controls
Deal Palm Button Operation (Pedestal Mounted)
Approximate Overall Dimensions: 128" L-R x 76" F-B x 182" H
Approximate Weight: 30,000 Lbs.(HEIGHT W/POWER UNIT ON TOP)
Serial Number: (New 1998)
P2 F.O.B. Elk Grove, IL - $ 19,500.00
* PRELIMINARY SPECIFICATIONS SUBJECT TO VERIFICATION
Email us at ****@PerfectionMachinery.com
Call our Sales Staff at 1-(***)-254-8808
Prices do not include any federal, state or local taxes, which are in addition to the purchase price and must be paid by the Purchaser. Any and all foreign duties and taxes are the responsibility of Purchaser. Unless Purchaser furnishes PMS with a tax exemption certificate, any sales, use, excise, or other similar tax, where applicable, shall also be the responsibility of Purchaser and may, at the election of PMS, be added to the quoted purchase price and invoiced by PMS to Purchaser. The failure of PMS to invoice such taxes does not excuse the Purchaser from responsibility for paying necessary taxes.
Some machinery and equipment is located at Fortune 100 Manufacturing Facilities. Most of the machinery and equipment located at these Facilities is disconnected and cannot be seen under power. Unless specifically listed in writing by PMS, all machinery and equipment uses 3 Phase power.
